Protocol validation occurs at the physical, data link, and transaction layers. In addition to the mandatory protocol compliance tests, the PCI-SIG® recommends more than a hundred additional tests to characterize PCIe designs accurately. Some of the most troubling PCIe issues occur during the bring-up sequence, where link partners fail to negotiate to the highest mutually supported speed, have high bit error rates, or operate in degraded modes. As a result, link training and status state machine (LTSSM) is crucial during protocol testing to ensure data packets transfer reliably between link partners.
PCIe protocol testing setup requires a protocol analyzer and exerciser. A protocol exerciser emulates both PCIe root complex and endpoint devices. The protocol analyzer acquires, records, decodes, and analyzes complex data from the physical layer all through the transactional layer. Combining the two instruments enables developers to create robust test cases and to quickly debug any detected errors in their PCIe devices.
How to Perform PCIe® 5.0 Protocol Validation
The Keysight P5552A PCIe 5.0 Protocol Analyzer introduces a new form factor that is easily deployable in the lab bench environment to enable deep protocol analysis of a PCIe system with unparallel signal integrity. Locate protocol errors or validate device operations by viewing data from the physical layer all through the transactional layer with ease.
Standards |
|
Max Data Rate | 32 GT/s |
How to Perform PCIe® 5.0 Protocol Validation
Keysight PCIe 5.0 Protocol Exerciser gives the flexibility in emulating either as a root complex or as an endpoint device when validating PCIe designs.
Standards |
|
Max Data Rate | 32 GT/s |
How to Perform PCIe® 5.0 Protocol Validation
The PCIe® 5.0 Protocol Testing solution consists of both hardware and software. The P5552A Protocol Analyzer, with the combination of the P5552PSWA Protocol Analyzer Traffic Analysis Software, gives the user a complete and total test solution for PCIe 5.0 protocol testing.
Software |
|
30-Day Free Trial License | N/A |
Max Data Rate | 32GT/s |
Standards |
|
How to Perform PCIe® 5.0 Protocol Validation
The PCIe® 5.0 Protocol Testing solution consists of both hardware and software. The P5551A Protocol Exerciser, with the combination of the P5551PSWA Protocol Exerciser Traffic Analysis Software, gives the user a complete and total test solution for PCIe 5.0 protocol testing.
Software |
|
30-Day Free Trial License | N/A |
Max Data Rate | 32GT/s |
Standards |
|
Additional resources for PCIe testing
Validating a PCIe® 6.0 DUT's protocol layer requires various conformance tests to ensure the device can successfully communicate with its link partner. Learn how to debug, validate, and optimize the protocol layer of your PCIe design.
Learn more
Impedance mismatch characterization in high-speed digital application design and test requires understanding the reflection signals in both the time and frequency domain. Learn how to measure hot S-parameter and hot TDR measurement, including eye diagram, using a network analyzer.
Learn more
Characterizing the forward error correction (FEC) performance of hyperscale data centers requires visibility into all ethernet lanes to detect and correlate meaningful errors. Learn how to set up an FEC test to quantify the bit error rate (BER) and FEC performance of different devices in bursty Ethernet traffic.
Learn more
